VOXL & VOXL 2 Microhard Modem Add-on with USB Hub

$199.99
| /
Selected sku: MDK-M0048-3-01
description



Long-range Point to Point Data-link for VOXL

Add significant point to point radio range to the VOXL and VOXL 2 platform using Microhard pDDL add-on carrier modules. Microhard modem to be purchased separately. This add-on in to the VOXL's board to board connector for a compact, SWAP-optimized radio and computing platform that can transcode video to a Microhard ground station.

Seamlessly Connect Your Drone to Laptop with Microhard

Supported Microhard Modules

Supported Microhard modules (not included in this kit):

  • 1800MHz pDDL1800 (Buy Here)
  • 2.4GHz MIMO pMDDL2450 (Buy Here)
  • 2.3GHz MIMO pMDDL2350



What's Included

MPN Description
MDK-M0048-3-01

Microhard Add-on Dev Kit

  • (1) MCCA-M0048 Add-on without Microhard modem module
  • (2) Antennas (Molex 47950-0011)
  • (1) Socket lid (MHS106010)


Additional Items Not Included

Microhard pMDDL modem

Technical Details

Datasheet


Compatible Products

Product Compatible?
VOXL ✅
VOXL Flight ✅
VOXL 2 ✅
VOXL 2 Mini ❌
Qualcomm Flight RB5 5G
 ❌
Sentinel ✅
VOXL 2 Flight Deck ✅


Export Information

Item Value
ECCN
 EAR99
Harmonized Tariff Schedule (HTS) Code 8542.31
Country of Origin USA
Radio Frequencies Used Module Dependent
