VOXL 2 WiFi Add-on and I/O Breakout
$79.00
| /
description
M0141 VOXL 2 USB2 Type A Breakout and I/O Add-On
Product Description
The M0141 USB2 Type A breakout gives VOXL 2 a standard USB 2.0 Type A female port, plus apps-processor UART, I2C and GPIO breakouts and a momentary fastboot switch. It is the usual way to add a Wi-Fi adapter to VOXL 2.
Product Specifications
| Feature | Details |
|---|---|
| USB | 1x USB 2.0 Type A female |
| I/O Breakout | Apps-processor UART, I2C and GPIOs (VOXL 2 only) |
| Switch | Momentary fastboot switch |
| Wi-Fi | 2.4 / 5 GHz via the bundled USB adapter (MDK-M0213-1-00) |
| Country of Origin | USA |
Software Features
- Wi-Fi managed by voxl-modem
- Fastboot switch supports recovery and unbricking workflows
Technical Details
M0213 Wi-Fi Adapter · VOXL 2 Wi-Fi Setup
What's Included
| MPN | Description |
|---|---|
| MDK-M0141-1-00 | Board only kit |
| MDK-M0141-1-01 | With Alfa Networks Wi-Fi adapter — obsolete |
| MDK-M0213-1-00 | With BotsUnlimited Wi-Fi adapter |
Additional Items Not Included
- VOXL 2 compute board
- USB Wi-Fi adapter, on the board-only kit
Compatible Products
| Product | Compatible? |
|---|---|
| VOXL 2 | ✅ |
| M0213 BotsUnlimited Wi-Fi adapter | ✅ |
| VOXL 2 Mini | ❌ use the USB3 port |
| VOXL / VOXL Flight / Qualcomm Flight RB5 5G | ❌ |
Export Information
| Item | Value |
|---|---|
| ECCN | EAR99 |
| Harmonized Tariff Schedule (HTS) Code | 8542.31 |
| Country of Origin | USA |
| Radio Frequencies Used | Wi-Fi 2.4 GHz / 5 GHz via the USB adapter |
| RoHS Compliant | Yes |
