5G Modem Carrier Board, USB HUB, I/O Breakout for VOXL 2
$269.99
| /
description
VOXL 2 5G Modem Carrier Board and USB Hub (MDK-M0090)
Product Description
Brings 5G cellular connectivity to a drone or robot built on VOXL 2. The carrier attaches directly to VOXL 2 over a high-speed board-to-board connector and adds an m.2 modem slot, a nano-SIM slot, USB 2.0 and USB 3.0 hubs and extra SPI and I2C I/O to the stack.
The board is designed for the Sierra Wireless EM9291 5G modem and will likely not work with other modems. It is available as a carrier board on its own, or as a kit with an NDAA-compliant EM9291 modem and antennas.
Product Specifications
| Feature | Details |
|---|---|
| Modem Slot | m.2 B-key card slot, for the Sierra Wireless EM9291 |
| SIM | nano-SIM card slot |
| USB | USB 2.0 hub and USB 3.0 hub |
| Additional I/O | (2) SPI, (2) I2C |
| Other | Fastboot switch |
| Host Interface | High-speed board-to-board connector to VOXL 2 |
| Dimensions | 67.5 mm x 36 mm x 10 mm |
| Weight | 12.8 g |
Software Features
- Managed by voxl-modem
Technical Details
What's Included
| MPN | Description |
|---|---|
| MDK-M0090-3-02-00 | Carrier board only — works only with the Sierra Wireless EM9291 |
| MDK-M0090-3-02-01 | Carrier board with Sierra Wireless EM9291 5G modem (NDAA-compliant) and antennas |
The antennas supplied with the -01 kit are Pulse Larsen W3907B0100 698–3600 MHz LTE/5G FPC antennas (datasheet).
Additional Items Not Included
- A VOXL 2 compute board
- A SIM and cellular data plan
- The Sierra Wireless EM9291 modem, if you order the -00 carrier-only variant
Compatible Products
| Product | Compatible? | Notes |
|---|---|---|
| VOXL 2 | ✅ | Board-to-board connector |
| Starling 2 Max | ✅ | Built around VOXL 2 |
| Sierra Wireless EM9291 5G modem | ✅ | The only modem this carrier is designed for |
| MCBL-00009-1, 4-pin JST to USB 2.0 Type A Female | ✅ | Optional, for the USB hub |
| VOXL and VOXL Flight | ❌ | VOXL 2 only |
Export Information
| Item | Value |
|---|---|
| ECCN | EAR99 |
| Harmonized Tariff Schedule (HTS) Code | No modem: 8542.31.0000 With modem: 8517.62.3000 |
| Country of Origin | USA |
| Radio Frequencies Used | 5G bands, determined by the installed modem |
| RoHS Compliant | Yes |
