Home / Collections / Blue UAS Framework Components / VOXL® 2 AI & 5G Development Drone - Sentinel

VOXL® 2 AI & 5G Development Drone - Sentinel

$3,699.99
| /
description

Ready to Fly Development Drone with VOXL® 2 Next Generation Blue UAS 2.0 Autonomous AI Autopilot

Sentinel is powered by Qualcomm® Flight RB5 technology, featuring VOXL® 2. VOXL 2 is the next generation Blue UAS Framework autopilot. At only 16g, VOXL 2 is the smallest single-board AI autopilot to date with premium tier processing from the Qualcomm QRB5165, a PX4 flight controller, advanced onboard AI and 5G connectivity.

Ready to Use Drone Development Tools

Powered by VOXL 2

  • 16 grams, 70x36mm SWAP-optimized autopilot
  • Powered by Qualcomm QRB5165: 8 cores up to 3.091 GHz, 8GB LPDDR5
  • 15 TOPS AI embedded Neural Processing Unit (NPU)
  • Integrated flight controller on DSP with TDK ICM-42688 IMU and ICP-10100 Barometer

    Add On Options

    • 1.8/2.3 or 2.4ghz point to point Microhard Modem
    • 5G, 4G/LTE, Microhard add-on connectivity

    Software Features

    • PX4, ROS 1 / 2, Debian Linux 9 (buster), Open CV, MAVROS, MAVSDK
    • Open Source Linux kernel, cross-compilers
    • Docker build environment for CPU, GPU (OpenCL) and DSP (Hexagon SDK) heterogeneous computer vision and deep learning processing

    What's Included

    Sentinel Version

    SKU

    Modem

    Cost

    Base

    MRB-D0006-4-V1.1-C11-M13-T7

    WiFi Dongle 2.4GHz / 5GHz

    ELRS 915MHz Receiver

    $3,699.99

    Point-to-point

    MRB-D0006-4-V1.1-C11-M3-T7

    Microhard Carrier (pDDL modem selected separately)

    & WiFi Dongle 2.4GHz / 5GHz

    & ELRS 915MHz Receiver

    $3,999.99

    5G

    MRB-D0006-4-V1.1-C11-M24-T7

    5G Carrier and Sierra Wireless EM9291

    & WiFi Dongle 2.4GHz / 5GHz

    & ELRS 915MHz Receiver

    $4,499.99



    Additional Items Not Included

    IMPORTANT: Limit of (2) batteries per drone ordered for international shipments. Please email contact@modalai.com for additional information.



    Technical Details

    Product Brief and Block Diagram

    Documentation

    VOXL 2 Feature Matrix

    Compatible Accessories



    Export Information

    Item Value
    ECCN
    EAR99
    Harmonized Tariff Schedule (HTS) Code 8542.31.3000
    Country of Origin USA
    Radio Frequencies Used

    WiFi Datasheet

    ELRS 915MHz

    Spektrum 2.4GHz





    Technical specifications

    • Autonomy

      • Powered by Qualcomm QRB5165: 8 cores up to 3.091GHz, 8GB LPDDR5
      • Seven MIPI image sensor inputs
      • Open CV, ROS 2, Docker, PX4 integrated flight controller
      • Integrated flight controller on DSP with TDK® ICM-42688 IMU and ICP-10111 Barometer
    • Artificial Intelligence

      • 15 TOPS of AI performance with industry leading power consumption
      • Onboard QRB5165: Hexagon Tensor Accelerator, GPU, DSP, NPU
      • Perception models such as object segmentation and depth from mono
      • NPU and GPU-accelerated TensorFlow Lite
    • Connectivity

      • WiFi, 4G/5G, Microhard

    Also available:

    • VOXL 2 Flight Deck

      Ready to mount flight deck with pre-calibrated image sensors.

      From $2,199.99

      Learn More

      ModalAI, Inc. Dev Kit (Beta) VOXL<sup>&reg;</sup> 2 Flight Deck

    Compare VOXL

    Find the right autopilot for you.
    Sentinel

    Price: from $3,699.99

    Size: 480mm diagonal

    Takeoff Weight: 1347g

    Flight Time: >20 minutes

    Payload Capacity: 1kg

    Compute: QRB5165

    Flight Controller: PX4

    Image Sensors: forward stereo, rear stereo, tracking, 4K high-res

    Connectivity: 4G/5G, WiFi

    Qualcomm Flight RB5 5G Platform

    Price: from $4,199.99

    Size: 480mm diagonal

    Takeoff Weight: 1235g

    Flight Time: >20 minutes

    Payload Capacity: 1kg

    Compute: QRB5165

    Flight Controller: PX4

    Image Sensors: forward stereo, rear stereo, tracking, 4K high-res

    Connectivity: 4G/5G, WiFi
